Numerical simulation research on flow fields in combined blown converter at steelmaking temperature
-
摘要: 以某鋼廠的110 t復吹轉爐為原型, 建立三維全尺寸幾何模型, 通過數值模擬的方法研究了環境溫度對多流股超音速氧氣射流特性的影響, 并對比分析了常溫和煉鋼溫度下氧氣射流對轉爐熔池的沖擊攪拌效果.研究結果表明:隨著環境溫度的升高, 氧氣射流的速度衰減減慢, 射流流股半徑增大, 與此同時, 射流本身的溫度升高、密度降低, 導致射流動壓的增加幅度低于射流速度的增加幅度;而且, 高溫環境中射流的聚合現象被抑制.在多相流研究中發現, 當環境溫度由300 K提高至1723K時, 氧氣射流的沖擊深度由0.11035 m升高至0.14807 m, 沖擊深度增大了34.18%, 熔池平均速度有一定提高, 說明在多相流研究中環境溫度的影響不容忽略.Abstract: Top and bottom combined blown converter has been widely utilized in steelmaking process.Multiple supersonic oxygen jets generated by top blown oxygen lance penetrate into the molten bath and form a penetration cavity on the surface of molten bath, which is the main reaction zone in steelmaking.Therefore, the characteristics of the multiple oxygen jets play a crucial role in converter flow fields and metallurgical performance.Several numerical and experimental studies have been conducted previously to investigate the supersonic oxygen jet.However, most of them were carried out at ambient room temperature by ignoring the high-temperature environment in steelmaking converters.In fact, the characteristics of supersonic oxygen jet are closely related to the ambient temperature.The effect of ambient temperature on single-stream oxygen jet has been previously studied, and it was confirmed that the jet characteristics improve with the increase in ambient temperature.Characteristics of multiple jets generated by converter oxygen lance at high ambient temperatures have not been previously studied.There are big differences between single-stream oxygen jet and multiple jets because the multiple jets deviate from the axis of oxygen lance.The coalescence phenomenon occurs in these multiple jets due to formation of low pressure zone between them.The difference between multiple jets characteristics at ambient room temperature and ambient steelmaking temperature inevitably leads to the difference between penetration cavity and flow fields in the converter, which has never been studied.To reveal the multiple jets characteristics and jet-bath interactions in converters at steelmaking temperature, a three-dimensional fullscale geometric model based on an industrial 110 t combined blown converter was established in this work.Using the combined blown converter model, coupled with standard k-epsilon turbulence model and volume of fraction multiphase model, the effect of ambient temperature on multiple oxygen jet characteristics was studied in detail.Moreover, jet-bath interactions at room temperature and steelmaking temperature were compared and analyzed.The results show that with the increase of ambient temperature, velocity attenuation of the multiple jets is inhibited and the radial expansion of the jets is aggravated.Meanwhile, the multiple jets are heated by the ambient medium, and the final temperature of multiple jets becomes close to ambient temperature, which decreases the jet density.Coalescence between multiple jets is suppressed in high ambient temperature.Research on the jet-bath interactions shows that penetration depth and flow velocity in molten bath are larger at steelmaking temperature because the velocity attenuation of supersonic jet is suppressed.These results indicate that the effect of ambient temperature in multiphase numerical researches is significant and cannot be ignored.
-
參考文獻
[1] Kataoka K, Takami T. Experimental study of eddy diffusion model for heated turbulent free jets. AIChE J, 1977, 23 (6) :889 [2] Sforza P M, Stasi W. Heated three-dimensional turbulent jets. J Heat Transfer, 1979, 101 (2) :353 [3] Corrsin S, Uberoi M S. Further experiments on the flow and heat transfer in a heated turbulent air jet[J/OL]. NASA Technical Reports Server (1949-04-28) [2017--08--13]. https://ntrs. nasa.gov/archive/nasa/casi. ntrs. nasa. gov/19930082540. pdf [4] Lau J C, Morris P J, Fisher M J. Measurements in subsonic and supersonic free jets using a laser velocimeter. J Fluid Mech, 1979, 93 (1) :1 [5] Sumi I, Kishimoto Y, Kikuchi Y, et al. Effect of high-temperature field on supersonic oxygen jet behavior. ISIJ Int, 2006, 46 (9) :1312 [6] Zhao F, Zhang Y L, Zhu R, et al. Numerical simulation of environment temperature effect on supersonic oxygen jet behavior. J Univ Sci Technol Beijing, 2014, 36 (5) :669 (趙飛, 張延玲, 朱榮, 等.環境溫度對超音速氧氣射流特性影響的數值模擬.北京科技大學學報, 2014, 36 (5) :669) [7] Li M M, Li Q, Li L, et al. Effect of operation parameters on supersonic jet behaviour of BOF six-nozzle oxygen lance. Ironmaking Steelmaking, 2014, 41 (9) :699 [8] Li M M, Li Q, Kuang S B, et al. Coalescence characteristics of supersonic jets from multi-nozzle oxygen lance in steelmaking BOF. Steel Res Int, 2015, 86 (12) :1517 [9] Liu F, Sun D, Zhu R, et al. Effect of nozzle twisted oxygen lance on flow field and dephosphorisation rate in converter steelmaking process. Ironmaking Steelmaking, 2017, 44 (9) :640 [10] Yang W Y, Ding Y L, Wang M L, et al. Water modeling of interaction between jets from multi-nozzle lance and bath in large converter. Iron Steel, 2004, 39 (3) :16 (楊文遠, 丁永良, 王明林, 等.大型轉爐多孔噴頭射流與熔池作用的水模研究.鋼鐵, 2004, 39 (3) :16) [11] Zhou L, Zhu B L, Wang J J. Study of hydraulic model experiment of lining protection with slag splashing in LBE. J East China Univ Metall, 2000, 17 (4) :282 (周俐, 朱本立, 王建軍.復吹轉爐濺渣護爐水模試驗研究.華東冶金學院學報, 2000, 17 (4) :282) [12] Ersson M, Tilliander A, Jonsson L, et al. A mathematical model of an impinging air jet on a water surface. ISIJ Int, 2008, 48 (4) :377 [13] Ersson M, H9glund L, Tilliander A, et al. Dynamic coupling of computational fluid dynamics and thermodynamics software:Applied on a top blown converter. ISIJ Int, 2008, 48 (2) :147 [14] Odenthal H J, Falkenreck U, Schlüter J. CFD simulation of multiphase melt flows in steelmaking converters//Proceedings of European Conference on Computational Fluid Dynamics. Egmond aan Zee, 2006:121 [15] Li Q, Li M M, Kuang S B, et al. Numerical simulation of the interaction between supersonic oxygen jets and molten slag-metal bath in steelmaking BOF process. Metall Mater Trans B, 2015, 46 (3) :1494 [16] Li Q, Li M M, Kuang S B, et al. Computational study on the behaviours of supersonic jets and their impingement onto molten liquid free surface in BOF steelmaking. Can Metall Q, 2014, 53 (3) :340 [17] He C L, Yang N C, Huang Q M, et al. A multi-phase numerical simulation of a four-nozzle oxygen lance Top-Blown Convertor.Procedia Earth Planet Sci, 2011, 2:64 -
