Influence of initial damage on degradation and deterioration of concrete under sulfate attack
-
摘要: 通過試驗研究含初始損傷混凝土在硫酸鹽腐蝕和干濕循環共同作用下的性能,分析了不同初始損傷程度混凝土隨腐蝕時間的增加,其質量、超聲波傳播速度、強度、單軸壓縮應力應變曲線以及聲發射活動的變化,運用損傷力學對腐蝕損傷進行定量評價和參數擬合,基于聲發射特性建立含初始損傷混凝土的腐蝕受荷損傷模型并進一步分析其損傷演化過程,借助環境掃描電鏡與電子能譜技術觀測分析受硫酸鹽腐蝕作用初始損傷混凝土微結構的變化,揭示其損傷機理.試驗結果表明,隨著腐蝕時間的增加,不同初始損傷程度混凝土的質量、超聲波傳播速度和強度均呈先增大后減小,初始損傷程度增加會加速混凝土在腐蝕作用下物理力學性能的劣化,其影響存在閾值,分別以抗壓強度、超聲波速為損傷變量可以建立混凝土的腐蝕損傷劣化方程,并進一步得出不同損傷表達式間的函數關系;相同腐蝕時間下,初始損傷的增加使聲發射活動減弱且產生明顯的聲發射的時間滯后;初始損傷下,基于聲發射特性的混凝土損傷演化過程可分為初期壓密階段、損傷穩定演化階段和損傷加速發展階段3個階段;初始損傷的增加使混凝土內部腐蝕反應更為活躍,微裂紋網絡體系比無初始損傷狀態下更加發達,呈現龜裂狀延伸和擴展,進而改變了混凝土的宏觀物理力學性質.Abstract: The variation of properties of concrete with initial damage under sulfate and wet-dry-cycle environments was experimentally investigated. With increased corrosion time, changes in the parameters of concrete with initial damage were analyzed, including mass, ultrasonic velocity, compressive strength, stress-strain curves, and the activities of acoustic emission under uniaxial compression. A quantitative evaluation and parameter fitting for corrosion damage was made based on damage mechanical theory. Based on the acoustic emission characteristics, a damage model of corroded concrete with initial damage was established and its damage evolution was analyzed. Using environmental scanning electron microscopy (ESEM) and energy-dispersive X-ray analysis (EDX), the damage mechanisms were revealed in observations of the microstructures and element compositions of concretes with initial damage induced by sulfate corrosion. The research results show that with increased erosion time, the mass, ultrasonic velocity, and compressive strength of concrete with different degrees of initial damage first increase and then decrease. Increases in the degree of initial damage may accelerate the degradation of physical and mechanical properties, but a threshold effect exists. Compressive strength and ultrasonic velocity can be regarded as damage variables, and corrosion damage evolution equations and the functional relationship between different damage formulas were established. With increased erosion time, the stress-strain curve of concrete with initial damage is obviously concave-upward and the elastic-stage time period can be comparatively shorter whereas the yield-stage time period increases. An increase in the degree of initial damage results in an obvious attenuation of the acoustic emission activity, which lags behind the time of the obvious acoustic emission response. Based on the acoustic emission characteristics, the damage evolution process of concrete with initial damage can be divided into three stages, including the compaction, stable damage evolution and development, and accelerating damage development stages. With an increase in the degree of initial damage, stronger corrosion reactions and composition changes occur inside the concrete. Compared to undamaged concrete, the expansion and extension of denser and deeper micro-cracks occur in concrete with initial damage under sulfate attack, which accelerates the degradation of the physical and mechanical properties of corroded concrete.
-
Key words:
- concrete /
- initial damage /
- sulfate attack /
- ultrasonic velocity /
- acoustic emission /
- damage evolution /
- microstructure
-
參考文獻
[3] Malezhik M P, Chernyshenko I S, Sheremet G P. Photoelastic simulation of the stress wave field around a tunnel in an anisotropic rock mass subject to shock load. Int Appl Mech, 2006, 42(8):948 [4] Sakaguchi M, Sasaki Y, Okazaki M, et al. Evaluation of fatigue crack propagation in the post-service gas turbine vane. J Solid Mech Mater Eng, 2010, 4(2):131 [5] Livne A, Bouchbinder E, Svetlizky I, et al. The near-tip fields of fast cracks. Science, 2010, 327(5971):1359 [6] Murakami Y. Analysis of stress intensity factors of modes I, Ⅱ and Ⅲ for inclined surface cracks of arbitrary shape. Eng Fract Mech, 1985, 22(1):101 [7] Yan X. Numerical analysis of the stress intensity factor for two kinds of mixed-mode crack specimens. J Strain Anal Eng Des, 2006, 41(1):9 [8] Smith C W, Post D, Hiatt G, et al. Displacement measurements around cracks in three-dimensional problems by a hybrid experimental technique. Exp Mech, 1983, 23(1):15 [9] Irwin G R. Elasticity and Plasticity/Elastizität und Plastizität. Heidelberg:Springer Berlin, 1958:551 [10] Bradley W B, Kobayashi A S. An investigation of propagating cracks by dynamic photoelasticity. Exp Mech, 1970, 10(3):106 [11] Schroedl M A, Smith C W. A study of near and far field effects in photoelastic stress intensity determination. Eng Fract Mech, 1975, 7(2):341 [12] Schroedl M A, McGowan J J, Smith C W. Determination of stress-intensity factors from photoelastic data with applications to surface-flaw problems. Exp Mech, 1974, 14(10):392 [13] Theocaris P S, Gdoutos E E. A photoelastic determination of KI stress intensity factors. Eng Fract Mech, 1975, 7(2):331 [14] Sanford R J, Dally J W. A general method for determining mixed-mode stress intensity factors from isochromatic fringe patterns. Eng Fract Mech, 1979, 11(4):621 [15] Okada H, Atluri S N, Omori Y, et al. Direct evaluation of Tε* integral from experimentally measured near tip displacement field, for a plate with stably propagating crack. Int J Plast, 1999, 15(9):869 [18] Ju Y, Xie H P, Zheng Z M, et al. Visualization of the complex structure and stress field inside rock by means of 3D printing technology. Chin Sci Bull, 2014, 59(36):5354 [19] Behrens B A, Bouguecha A, Vucetic M, et al. Characterisation of the quasi-static flow and fracture behaviour of dual-phase steel sheets in a wide range of plane stress states. Arch Civil Mech Eng, 2012, 12(4):397 [20] Humbert C, Decruppe J P. Flow birefringence and stress optical law of viscoelastic solutions of cationic surfactants and sodium salicylate. Eur Phys J B-Condens Matter Complex Syst, 1998, 6(4):511 [22] Murakami Y, Keer L M. Stress intensity factors handbook, Vol. 3. J Appl Mech, 1993, 60(4):1063 -
