Simulation and performance study of low-power magnetron sputtered ZnO methane sensor
-
摘要: 隨著微機電系統(MEMS)的發展，運用該技術的半導體傳感器也跟著迅速發展，逐漸走向微型化、集成化和智能化。基于MEMS的微加熱板(MHP)的金屬氧化物甲烷傳感器具有功耗小、響應快等優點，廣泛應用于甲烷檢測。其中，氧化鋅(ZnO)甲烷敏感材料因其靈敏度高、中毒效應小、工作溫度低等優點，廣受關注。但是，該敏感材料制備的傳感器響應性能依然受加熱溫度及熱量分布的強烈影響。使用有限元分析(FEA)軟件COMSOL中的Multiphysics模塊對物理場中的溫度進行仿真分析與比較，揭示了在相同工作條件下加熱電極結構對溫度分布的影響，優選的微加熱板達到300 ℃時需要75 mW左右的功率。在商用微加熱板的叉指電極上采用無遮擋全表面濺射氧化鋅敏感材料構建ZnO薄膜甲烷傳感器，并使用合肥微納公司HIS9010測試了氣體傳感器的響應。采用靜態測量的方法向1 L的氣體腔內注射甲烷氣體，經過測試，與現在不同形貌的ZnO相比，本課題組使用的磁控濺射制備的氧化鋅薄膜氣體傳感器，在(1000～10000)×10?6甲烷濃度區間內響應線性度比較好，對濃度為10000×10?6的甲烷響應值達到了30。與國內外商用甲烷傳感器的甲烷響應性能進行了對比，結果表明本課題組制作傳感器響應更高，更具有應用優勢。Abstract: With the development of the industry of semiconductor integrated circuits, microelectromechanical system (MEMS) products have made rapid progress. The development of MEMS and the combination of sensor technology have yielded compact sensors with increased functions and intelligence levels. MEMS-based microhotplate (MHP)-type metal oxide methane sensors have the advantages of low power consumption and fast response and have been widely used in methane detection applications. In particular, ZnO methane-sensitive materials have attracted significant attention due to their high sensitivity, small poisoning effect, and low operating temperature. Notably, the response performance of sensors prepared from these sensitive materials is still significantly affected by the heating temperature and thermal distribution of the MEMS-based MHP. The purpose of our experiment is to optimize the heat generation of the heating electrodes of MHP, optimize the thermal distribution of MHP, and further reduce the power consumption of MHP sensors. The heating electrodes of MHP are made of platinum materials that have high thermal conductivity and stable performance. In this study, we use the Multiphysics module in the finite element analysis software COMSOL to simulate and analyze the temperature in the physical field for the two structures of serpentine platinum heating electrodes of MHP. By comparison, the structure of the heating electrodes affects the temperature distribution under the same working conditions. The structure with a larger width in the middle of the heating plate electrode and gradually narrowing to both sides generates more heat than that with the same width. When the heating plate reaches 300 ℃, it needs about 75 mW of power. Next, ZnO thin film methane sensors were constructed by sputtering ZnO methane-sensitive materials on the interdigital electrode of a commercial MHP, and the response of the gas sensor was tested using the HIS9010 of Hefei Micro-Nano Company. The static measurement method was used to inject methane gas into a 1-L gas chamber. In order to verify the superior response of our sensor, it has been compared that performance of commercial methane sensors and ZnO methane sensors made by. The response linearity in the interval is relatively good, and the response value for 10000×10?6 methane reaches 30. The response of our fabricated sensor is higher than those of existing domestic and foreign commercial methane sensors, showing significant potential in related applications.
-
Key words:
- methane sensor /
- micro hotplate /
- finite element analysis /
- magnetron sputtering /
- zinc oxide
-
圖 1 傳感器圖示. (a) 傳感器掃描電鏡圖; (b)傳感器裸芯片細節示意圖
Figure 1. Images of sensor: (a) scanning electron microscope image of sensor chip; (b) details of the sensor schematic
圖 3 不同結構氣體傳感器芯片溫度仿真結果圖. (a) 結構1; (b) 結構2
Figure 3. Simulation result graph of gas sensor chip temperature with different structures: (a) stucture 1; (b) stucture 2
圖 4 不同微加熱器板結構在不同加熱電壓下的溫度. (a) 結構1; (b) 結構2
Figure 4. Temperature distribution of different heating voltages for different structures: (a) structures 1; (b) structure 2
圖 5 制作傳感器所用磁控濺射儀器及濺射流程圖. (a) 磁控濺射儀; (b) 磁控濺射流程圖
Figure 5. Magnetron sputtering instrument and flowchart for making sensor: (a) magnetron sputterer used; (b) magnetron sputtering flowchart
圖 6 傳感器表征圖. (a) SEM圖; (b) EDS分布數據; (c)EDS元素分布
Figure 6. Characterization diagram of sensor: (a) SEM; (b) EDS distribution data; (c) EDS elemental distribution
圖 8 不同加熱電壓ZnO微熱板傳感器響應. (a) 加熱電壓1.2 V; (b) 加熱電壓1.8V; (c) 加熱電壓2.2 V
Figure 8. Response to ZnO MHP sensor at different heating voltage: (a) heating voltage of 1.2 V; (b) heating voltage of 1.8 V; (c) heating voltage of 2.2 V
圖 9 傳感器在不同氣氛中的表面電子能級示意圖. (a) 空氣中; (b) 還原性氣體中
Figure 9. The surface electron energy diagram of sensor under different gas atomspheres: (a) in air; (b) sensor in reducing gas
表 1 微加熱板底座及加熱板尺寸
Table 1. MHP base and heating plate dimensions
Structure attribute Specification Silicon substrate Substrate size 1 mm× 1 mm× 0.5 mm Width of platinum heating resistance 1 Width is 12 mm; interval is 10 mm;
thickness is 300 nmWidth of platinum heating resistance 2 Platinum heaters with unequal width. Adjacent spacing is 9 mm; thickness is 300 nm The resistivity of the heating resistance 0.0019 K?1
下載: 導出CSV
表 2 甲烷響應對比
Table 2. Comparison of methane responses
Preparation method Methane concentration / 10?6 S References Preparation of ZnO graded structure by hydrothermal method 1000 2.5 [26] ZnO was modified by drop coating with palladium 5000 20 [27] ZnO was modified by g-C3N4 10000 29 [28] Zhengzhou Winsen Electronics Technology Co., Ltd MP-4 1000 10 [9] FIGARO TGS3870 10000 19 [13] Magnetron sputtering ZnO films 1000/5000/10000 12/21/30 This work
下載: 導出CSV
