鋁棒低銀鉛合金表面陶瓷化復合陽極的制備與性能

閆文凱; 陳步明; 冷和; 黃惠; 郭忠誠; 徐瑞東

doi:10.13374/j.issn2095-9389.2018.11.04.002

鋁棒低銀鉛合金表面陶瓷化復合陽極的制備與性能

doi: 10.13374/j.issn2095-9389.2018.11.04.002

閆文凱¹⁾,
陳步明^{1), 2), ,},
冷和²⁾,
黃惠^{1), 2)},
郭忠誠^{1), 2)},
徐瑞東¹⁾

1).
昆明理工大學冶金與能源工程學院, 昆明 650093
2).
昆明理工恒達科技股份有限公司, 昆明 650106

基金項目:

國家自然科學基金資助項目 51564029

國家自然科學基金資助項目 51874154

國家自然科學基金資助項目 51504111

云南省技術創新人才培養對象資助項目 2019HB111

昆明理工大學分析測試基金資助項目 2017T20090100

昆明理工大學分析測試基金資助項目 2017M20162102014

詳細信息

通訊作者:
陳步明, E-mail: linxinyoou@fzu.edu.cn

中圖分類號: TG142.71
計量
- 文章訪問數: 1127
- HTML全文瀏覽量: 410
- PDF下載量: 15
- 被引次數: 0
出版歷程
- 收稿日期: 2018-11-04
- 刊出日期: 2019-10-01

Preparation and properties of Al-rod-Pb-0.2%Ag composite anode by surface ceramization

YAN Wen-kai¹⁾,
CHEN Bu-ming^{1), 2)
, ,},
LENG He²⁾,
HUANG Hui^{1), 2)},
GUO Zhong-cheng^{1), 2)},
XU Rui-dong¹⁾

1).
School of Metallurgical an Energy Engineering, Kunming University of Science and Technology, Kunming 650093, China
2).
Kunming Hendera of Science and Technology Co. LTD., Kunming 650106, China

More Information

Corresponding author: CHEN Bu-ming, E-mail: linxinyoou@fzu.edu.cn

摘要

摘要: 為獲得一種鋅電積用低成本、低析氧電位和高催化活性的陽極，在鋁棒表面通過擠壓復合技術包覆Pb-0.2% Ag合金得到Al棒Pb-0.2% Ag陽極.在含氟的硫酸溶液中，通過陽極氧化在Pb-0.2% Ag合金和Al棒Pb-0.2% Ag合金陽極表面形成具有高催化性能的膜層，采用顯微圖像分析儀和數顯顯微硬度計表征了膜層的厚度及硬度，并通過電子拉伸試驗對比了兩種陽極的極限抗拉強度.采用X射線衍射、掃描電子顯微鏡、循環伏安法、陽極極化和交流阻抗法等技術手段研究了Al棒Pb-0.2% Ag與Pb-0.2% Ag陽極表面氧化膜層的物相、形貌以及電化學性能.結果表明：Al棒Pb-0.2% Ag陽極相比Pb-0.2% Ag陽極表面易生成致密較厚的氧化膜層，且膜層硬度提升了41.64%，其氧化膜層主要物相均為電催化活性良好的β-PbO₂.新型陽極的極限抗拉強度是傳統陽極的1.3倍，大大改善了陽極材料的機械性能.陽極極化曲線數據顯示Al棒Pb-0.2% Ag/PbO₂陽極在電積鋅體系中具有較低的析氧電位(1.35 V vs MSE，500 A·m^-2)和較高的交換電流密度(7.079×10^-5 A·m^-2).循環伏安曲線和交流阻抗數據顯示Al棒Pb-0.2% Ag/PbO₂陽極具有較高的電催化活性、較大的表面粗糙度和較小的電荷傳質電阻.在電積鋅實驗中，柵欄型Al棒Pb-0.2% Ag/PbO₂陽極相比傳統Pb-0.2% Ag陽極平均槽電壓下降了75 mV，而且大大減少了陽極泥的產生.
- Al棒Pb-0.2%Ag /
- 表面陶瓷氧化 /
- 鋅電積 /
- 機械性能 /
- 電催化活性
Abstract: To obtain a low-cost anode with low oxygen evolution potential and high catalytic activity for zinc electrowinning, Pb-0.2%Ag alloy was coated on an aluminum matrix surface by extrusion cladding technology, and a film layer with high catalytic performance was formed on the surface of the Pb-0.2%Ag alloy and Al-rod-Pb-0.2%Ag anode by anodization in a fluorine-containing sulfuric acid solution. The thickness and hardness of the film were studied using a microscopic image analyzer and digital microhardness tester, and the ultimate tensile strengths of the two anodes were compared using an electronic tensile tester. The phase, morphology, and electrochemical performance of the Al-rod-Pb-0.2%Ag and Pb-0.2%Ag anode surface film were investigated using X-ray diffractometry, scanning electron microscopy, cyclic voltammetry, anodic polarization, and electrochemical impedance spectroscopy. The results show that the Al-rod-Pb-0.2%Ag anode surface forms a dense and thick oxide film layer more easily than the Pb-0.2%Ag anode and the hardness of the film layer is increased by 41.64%; moreover, the main phase is β-PbO₂, and the oxide film layer exhibits good electrocatalytic activity. The ultimate tensile strength of the new anode was 1.3 times that of the traditional anode, which greatly improves the mechanical properties of the anode material. Analytical data of anodic polarization curves reveal that the Al-rod-Pb-0.2%Ag/PbO₂ anode shows low oxygen evolution potential (1.35 V vs MSE, 500 A·m^-2) and high exchange current density (7.079×10^-5 A·m^-2) in zinc electrowinning system. Analytical data of cyclic voltammetry and EIS curves indicate that the Al-rod-Pb-0.2%Ag/PbO₂ anode has higher electrocatalytic activity, larger surface roughness, and smaller charge transfer resistance. In the zinc electrowinning experiment, the average cell voltage of the fence-like Al-rod-Pb-0.2%Ag/PbO₂ anode was 75 mV less than that of the traditional Pb-0.2% Ag anode, and the production of anode slime was greatly reduced.
- Al-rod-Pb-0.2%Ag /
- surface ceramic oxidation /
- zinc electrowinning /
- mechanical properties /
- electrocatalytic activity

HTML全文

圖 1 鉛合金包覆鋁棒示意圖

Figure 1. Schematic diagram of lead alloy-coated aluminum wire

下載: 全尺寸圖片幻燈片

圖 2 陽極氧化裝置示意圖

Figure 2. Schematic diagram of anodizing equipment

下載: 全尺寸圖片幻燈片

圖 3 Al棒Pb-0.2%Ag與Pb-0.2%Ag陽極表面膜層X射線衍射圖譜

Figure 3. XRD patterns of Al-rod-Pb-0.2%Ag and Pb-0.2%Ag anode surface film

下載: 全尺寸圖片幻燈片

圖 4 不同陽極表面膜層掃描電鏡圖. (a, c) Al棒Pb-0.2%Ag; (b, d) Pb-0.2%Ag

Figure 4. SEM of different anode surface layers: (a, c) Al-rod-Pb-0.2%Ag; (b, d) Pb-0.2%Ag

下載: 全尺寸圖片幻燈片

圖 5 不同陽極材料的表面膜層截面金相及力學性能.(a) Al棒Pb-0.2%Ag; (b) Pb-0.2%Ag; (c) 極限抗拉強度; (d) 膜層厚度與維氏硬度

Figure 5. Metallographic and mechanical properties of the surface layer of different anode materials: (a) Al-rod-Pb-0.2%Ag; (b) Pb-0.2%Ag; (c) ultimate tensile strength; (d) Vickers hardness and thickness of surface layer

下載: 全尺寸圖片幻燈片

圖 6 不同陽極材料在50 g·L^-1 Zn²⁺, 150 g·L^-1 H₂SO₄溶液中的循環伏安曲線. (a) 全譜; (b) “c”峰

Figure 6. Cyclic voltammetry curves of different anode materials in 50 g·L^-1 Zn²⁺, 150 g·L^-1 H₂SO₄ solution: (a) full spectrum; (b) "c" peak

下載: 全尺寸圖片幻燈片

圖 7 不同陽極材料在50 g·L^-1 Zn²⁺, 150 g·L^-1 H₂SO₄溶液中的析氧動力學分析.(a) 陽極極化曲線; (b) Tafel擬合曲線

Figure 7. Oxygen evolution analysis of different anode materials in 50 g·L^-1 Zn²⁺, 150 g·L^-1 H₂SO₄ solution: (a) anode polarization curves; (b) Tafel fitting curves

下載: 全尺寸圖片幻燈片

圖 8 不同陽極材料在50 g·L^-1 Zn²⁺, 150 g·L^-1 H₂SO₄溶液中的交流阻抗圖. (a) 阻抗圖譜; (b) Bode圖; (c) 擬合電路圖

Figure 8. EIS spectra of the different anode materials in 50 g·L^-1 Zn²⁺, 150 g·L^-1 H₂SO₄ solution: (a) Nyquist diagrams; (b) Bode plots; (c) electrical equivalent circuit used to simulate impedance data for OER on composite electrode material

下載: 全尺寸圖片幻燈片

圖 9 柵欄型陽極板實物圖. (a, b) 電解前; (c, d) 電解15 d后

Figure 9. Physical photo of palisade anode plate: (a, b) before electrolysis; (c, d) after 15 days of electrolysis

下載: 全尺寸圖片幻燈片

圖 10 不同陽極電解過程中的槽電壓的變化

Figure 10. Change of cell voltage during electrolysis of the different anodes

下載: 全尺寸圖片幻燈片

表 1 不同陽極材料的析氧反應動力學參數

Table 1. Kinetic parameters of oxygen evolution for the different anode materials

陽極試樣	η/V		a₁	b₁	a₂	b₂	J₀/(A·m^-2)
陽極試樣	500 A·m^-2	1000 A·m^-2	a₁	b₁	a₂	b₂	J₀/(A·m^-2)
Pb-0.2%Ag	0.894	0.951	1.142	0.191	1.266	0.442	1.049×10^-6
Pb-0.2%Ag/PbO₂	0.794	0.861	1.083	0.222	1.182	0.438	1.323×10^-5
Al棒Pb-0.2%Ag	0.874	0.935	1.139	0.204	1.247	0.428	2.610×10^-6
Al棒Pb-0.2%Ag/PbO₂	0.741	0.819	1.079	0.260	1.171	0.454	7.079×10^-5

下載: 導出CSV

表 2 不同陽極材料交流阻抗譜的等效電路參數

Table 2. Equivalent circuit parameters of the EIS spectra of the different anode materials

陽極試樣	R_s/(Ω·cm²)	R_t/(Ω·cm²)	Q_dl/(Ω^-1·cm^-2·sⁿ)	n	C_dl/(μF·cm^-2)	RF
Pb-0.2%Ag	0.122	9.532	0.001	0.852	198	9.9
Pb-0.2%Ag/PbO₂	0.127	3.176	0.020	0.980	17712	885.6
Al棒Pb-0.2%Ag	0.114	6.423	0.007	0.793	1067	53.4
Al棒Pb-0.2%Ag/PbO₂	0.088	2.84	0.044	0.898	23308	1165.4

下載: 導出CSV

表 3 電積鋅實驗條件

Table 3. Experimental conditions for zinc electrodeposition

電解液	電流密度/(A·m^-2)	溫度/℃	陽極	陰極
150 g·L^-1 H₂SO₄+50 g·L^-1Zn²⁺+1 g·L^-1 C1^-	500	35	試樣1#和2#	純鋁
備注：試樣1#代表圖 9(a) Al棒Pb-0.2%Ag; 試樣2#代表圖 9(b) Al棒Pb-0.2%Ag/PbO₂.

下載: 導出CSV
